Canon Patent: Head Mounted Display For Photographic Information

Canon Patent
View Post

A new Canon patent, and I am not sure I understood it entirely.

Canon patent application 2023179231 (Japan, published 12/19/2023) discusses technology and methods for a “head mounted display” that shows photographic information “according to the photographer’s line of sight”. Is this some sort of smart glasses that display information?

From the patent literature:

  • An object of the present invention is to provide a photographing device system having a display member that displays scale information of an operation ring according to the line of sight of a photographer.
  • Conventionally, in order to display photographing information on a head-mounted display device, a system has been proposed in which information is displayed on one of the display sections within the left and right visual fields, as disclosed in Patent Document 1, for example.
  • In the conventional example, an operation on the camera side was required to display information on photographic equipment on the display section. Therefore, when both hands cannot be used for the operation of photographing itself, it is difficult to instantly display the status of necessary parts of the photographic equipment.
  • Accordingly, an object of the present invention is to provide a photographing apparatus system having a display device that is attached to the head and displays the status of necessary photographic equipment according to the photographer’s line of sight.
  • Means for Solving the Problems
    In order to achieve the above object, the present invention provides a lens having a manually operated member and a movable lens group that is driven according to the amount of operation of the manually operated member; It is a head-mounted display device that displays images shot through the lens, and the head-mounted display device includes a display section that divides the display content into left and right sides, and a display section that displays images taken by the head-mounted display device. It has a camera unit that photographs the direction of the person’s line of sight, the manual operation member has a scale marker, and the display unit displays photographing information of the lens at a position near the scale marker. do.
  • Next, a flow for the photographer 50 to obtain photographing information such as the focus, zoom, and iris of the lens 30 during photographing will be described. FIG. 2 shows a state in which the photographer 50 directs his/her line of sight in the direction of the focus ring 31 in order to obtain focus information. The display section 2b on the right eye side of the HMD 1 displays an image captured by the camera 20. One display section 2a is in a state where the surface of the lens 30 is visible through the display section 2a.

Comments welcome :-)

More Canon patents are listed here.

[via asobinet]

Canon Patent: Tilting EVF For Mirrorless Camera

Canon Patent
View Post

Here is a new Canon patent application: a tilting Electronic ViewFinder (EVF) for mirrorless cameras. Rather interesting.

Canon patent application  2023-178037 (Japan, published 12/14/2023) discusses technology and methods for a tiltable EVF to build into a mirrorless camera.

From the patent literature:

  • An object of the present invention is to limit movement and deformation of a flexible substrate in response to movement and rotation of a movable unit.
  • BACKGROUND ART
    A display unit such as an electronic viewfinder installed in an imaging device can be pulled out from the main body of the imaging device, and can be rotated in the pulled out state, so that the user can take an image. There is something that expands the degree of freedom in posture.
  • Patent Document 1 discloses an imaging device equipped with a finder unit that can be pulled out and rotated. In this imaging device, a flexible board is used for electrical connection between the board provided in the finder unit and the control unit fixed to the main body, and the flexible board changes as the finder unit is pulled out and rotated relative to the main body. transform.
  • However, in the imaging device disclosed
    in Patent Document 1, there are insufficient restrictions on the movement and deformation of the flexible substrate in response to the pull-out and rotation of the finder unit relative to the main body. Therefore, there is a risk that an excessive load will be applied to the flexible substrate or that the flexible substrate will be caught between other members.
  • The present invention provides an electronic device in which excessive load or pinching of the flexible substrate can be avoided by restricting the movement and deformation of the flexible substrate in accordance with the movement and rotation of a movable unit such as a display unit. provide.

More Canon patents are listed here.

[via asobinet.com]

Save 25% On Topaz Photo AI and Video AI (limited time)

Photo Ai
View Post

For the holidays, Topaz Labs started a promotion on their award winning products, Photo AI and Video AI, which are 25% off.

You can get Photo Ai at $149 (reg. $199) and Video AI at $224 (reg. $299) – see here for trial version and more information.

More selected deals:

Canon Patent: 70-150mm f/2 and 70-200mm f/2.8 With Inner Zoom

Canon Patent
View Post

Here is a new Canon patent application, two lenses with inner zoom mechanism.

Canon patent application 2023176289 (Japan, published 12/13/2023) discusses optical formulas and methods for two zoome lenses with a not extending zoom mechanism:

  • 70-150mm f/2
  • 70-200mm f/2.8

From the patent literature:

  • An object of the present invention is to provide a zoom lens that has a long focal length and a large aperture ratio, yet is both compact and lightweight and has high optical performance.
  • BACKGROUND ART
    Zoom lenses used in imaging devices are required to be small and lightweight, to satisfactorily correct various aberrations including chromatic aberration, and to have high optical performance. Furthermore, zoom lenses are required to have a long focal length at the telephoto end, a small F number, and a large aperture ratio. Furthermore, zoom lenses are required to have a large zoom ratio and be easy to manufacture.
  • However, the zoom lens described in Patent Document 1 tends to have large aberrations including chromatic aberration, making it difficult to have high optical performance. If the power of the lens groups making up the zoom lens is weakened in order to better correct the aberrations, the zoom lens will become larger. Furthermore, if aberrations are corrected by increasing the number of lens groups that make up the zoom lens, the mechanical mechanism will become complicated and the zoom lens will become larger.
  • The present invention provides a zoom lens that has a long focal length and a large aperture ratio, yet is both compact and lightweight and has high optical performance.

Example 1

  • Focal length: 72.10-146.49
  • F value: 2.05
  • Half angle of view: 16.70-8.40
  • Image height: 21.64
  • Total length: 217.31
  • Back focus: 13.71

Example 2

  • Focal length: 72.12-194.03
  • F value: 2.90
  • Half angle of view: 16.70-6.36
  • Image height: 21.64
  • Total length: 217.47
  • Back focus: 37.98

Example 3

  • Focal length: 98.00-291.00
  • F value: 2.90
  • Half angle of view: 12.64-4.25
  • Image height: 21.64
  • Total length: 317.42
  • Back focus: 38.00

Example 4

  • Focal length: 101.97-389.88
  • F value: 4.10
  • Half angle of view: 11.98-3.18
  • Image height: 21.64
  • Total length: 359.04
  • Back focus: 52.64

More Canon patents are listed here.

[via asobinet]

Nikon Made A Special Firmware For NASA, To Avoid Cosmic Rays In Photos

Nikon Z 9
View Post

Well, if this is not a nice technological thing by Nikon. Making a special firmware to block cosmic rays in photos.

In an interview with PetaPixel, astronaut Don Pettit talks about the changes that Nikon made to firmware.

Excerpt from the interview:

“Our cameras in space get sensor damage from galactic cosmic rays and after about six months we replace all the cameras but you still have cameras with significant cosmic ray damage,” explains Pettit.

“It shows up at fast shutter speeds, not just the slow ones. So we got Nikon to change the algorithm so that it can do in-camera noise reduction at shutter speeds of up to 500th of a second.”

Pettit says Nikon’s in-camera noise reduction “does wonders” for getting rid of the cosmic ray damage and that “trying to get rid of it after the fact is really difficult.”

NASA used to use Hasselblad cameras, but then started using Nikon cameras. Apparently , there are between 12 and 15 Nikon D5 cameras on the ISS (International Space Station). According to Don Pettit, they are “in the process of switching over to the Z9 and [they are] going to slowly replace the lenses with the Z lenses, initially replacing the lenses that require the mechanical autofocus.“
