Another Canon Patent For A 24-70mm f/2.8 Image-Stabilized Lens

Egami (translated) spotted a Canon patent for a 24-70mm f/2.8 IS lens. This is the fourth time I am posting about such a patent (the other patents: 1 | 2 | 3).

• Patent Publication No. 2014-52413,2014-52445
  • Publication date 2014.3.20
  • Filing date 2012.9.5
• Example 1
  • Zoom ratio 2.75
  • Focal length f = 24.7-35.21-68mm
  • Fno. 2.9
  • Half angle ω = 41.21-31.57-17.65 °
  • Image height 21.64mm
  • 223.94-207.87-180.56mm overall length of the lens
  • BF 38.31mm

[via Egami]
