Canon working on miniaturisation of shutter mechanism, patent application

canonIs there something coming from Canon, something small? After a patent application to improve the durability of a shutter mechanism, we also spotted a Canon patent application describing how to miniaturise the shutter mechanism.

Canon patent application P2018-010054A describes methods to further miniaturise the shutter mechanism:

The present invention relates to a blade drive device for driving blades entering and leaving an optical path, and an image pickup device including the blade drive device, for example, an IR (infrared light) cut filter and an AR (anti-reflection) A filter switching device for switching the filter, and a device incorporated in a lens barrel of a video camera or a surveillance camera equipped with such a filter switching device.

More Canon patent applications.

Canon working to improve durability of shutter mechanism, patent application suggests

canon patentCanon patent application JP-A-2018-10053 describes how to improve the durability of shutter blades.

Claims:

An opening forming member in which an opening serving as an optical path is formed, First and second shutter blades which enter and leave the opening, A drive transmission member engaged with the first and second shutter blades for transmitting a driving force, And a stopper for stopping the movement of the blade by abutment of the first and second shutter blades when the optical path is blocked by the first and second shutter blades in the opening,
Wherein the first and second shutter blades each include a shutter portion for shielding the optical path in the opening portion, an engaging portion for engaging with the drive transmission member, and a connecting portion for connecting the shutter portion and the engaging portion with each other Has,
Wherein the stopper includes a main stopper in which one side of the engaging portion side of the first and second shutter blades abuts and a second stopper provided between the opening and the drive transmission member and on one side of the connecting portion And a sub-stopper with which the portion abuts.

It’s good to see that Canon’s R&D are working on the really useful things. More Canon patent applications.

This cool beat is made of camera shutter sounds



Ever thought that the “click” of your camera’s shutter mechanism might be used to compose a beat? Well, bear with us.

The Shutterlog Remix Reupload video (1 minute) above is exactly that: a cool beat made up from camera shutter sounds.

The Phoblographer spotted the video and had a closer look at the cameras used in the video:

[…] from 35mm SLRs, to point and shoot cameras, to toy cameras and novelty snappers, to medium format cameras and some iconic Polaroids

Well, the result is definitely listenable, and a pleasure to view. Enjoy!
