Canon Patent For 600mm f/4 Lens

Canon Patent

Egami (translated) spotted a patent filed by Canon for a new 600mm f/4 lens. Egami suggests the lens will be ready for Tokyo Olympic Games in 2020 and the Rio de Janeiro Olympic Games in 2016.

  • Patent Publication No. 2014-26210
    • Publication date 2014.2.6
    • Filing date 2012.7.30
  • Example 1
    • Focal length f = 588mm
    • Fno. 4.12
    • Angle of view 2ω = 4.22 °
    • BF 56.0mm
    • Total lens length 374.7mm
    • Inner focus
  • Example 5
    • Focal length f = 588mm
    • Fno. 4.12
    • Angle of view 2ω = 4.22 °
    • BF 55.0mm
    • Total lens length 343.5mm
    • Inner focus
    • Diffraction optical element
  • Effect of the glass material
    • Fluorite (Fluorite)
      • In the long lens fluorite + total length, correction of chromatic aberration is easy
      • In short lens fluorite + total length, correction of chromatic aberration is difficult
    • Diffractive optical element (DOE)
      • Diffractive optical element can be corrected if the chromatic aberration
      • Flare caused by light diffraction

Canon Patent for 24-85mm and 24-70mm Lenses (with Macro)

pat

Lots of Canon patents surfaced in the last weeks. Here is another one spotted by Egami (translated). If I got the (machine-) translated text right, both lenses should also feature macro capabilities.

  • Patent Publication No. 2014-16464,2014-16465
    • Publication date 2014.1.30
    • Filing date 2012.7.9
  • Example 3
    • Macro when in parentheses
    • Zoom ratio 2.84 (2.87)
    • Focal length f = 24.30-35.10-69.00mm (67.23-60.62)
    • Fno. 4.10 (5.28-5.56)
    • Half angle ω = 41.68-31.65-17.41 ° (17.84-19.64)
    • Image height Y = 21.64mm
    • 134.65-141.04-164.94mm overall length of the lens (162.09-152.75)
    • BF 39.15-46.02-59.68mm (64.95-67.73)
    • β = -0.17 (-0.7)
  • Example 4
    • Macro when in parentheses
    • Zoom ratio 3.42 (2.84)
    • Focal length f = 24.30-35.10-82.99mm (68.22-64.03)
    • Fno. 3.58-4.42-5.89 (5.92-5.87)
    • Half angle ω = 41.68-31.65-14.61 ° (17.60-18.67)
    • Image height Y = 21.64mm
    • 126.64-128.32-155.92mm overall length of the lens (149.57-148.58)
    • BF 39.39-49.31-64.14mm (65.59-65.96)
    • β = -0.17 (-0.6)
  • Canon patents
    • (4, etc. as in Example 3) seven-group zoom of positive and negative positive and negative positive positive and negative
    • (4, etc. the second group, as in Example 3) inner focus
    • implement the macro function by the first group fed out to the object side

Canon Patent for 17-55mm and 18-55mm STM Lenses (new kit lenses?)

Untitled

Egami (translated) found a patent filed by Canon that appears to refer to new kit lenses: 17-55mm f/3.5-5.6 STM and 18-55mm f/3.5-5.6 STM. s you can see both lenses feature Canon’s newer STM (stepping motor) technology to drive the lens. STM is almost silent when operating, hence useful for videography.

  • Patent Publication No. 2014-21258
    • Publication date 2014.2.3
    • Filing date 2012.7.18
  • Example 2
    • Zoom ratio 2.92
    • Focal length f = 18.50-32.89-54.00mm
    • Fno. 3.49-4.39-5.80
    • Half angle ω = 36.44-22.55-14.20 °
    • Image height Y = 13.66mm
    • 119.77-110.06-120.23mm overall length of the lens
    • BF 37.98-52.51-74.3mm
  • Example 3
    • Zoom ratio 3.09
    • Focal length f = 17.50-32.05-54.00mm
    • Fno. 3.47-4.38-5.80
    • Half angle ω = 37.97-23.08-14.20 °
    • Image height Y = 13.66mm
    • 119.55-108.81-118.68mm overall length of the lens
    • BF 36.59-51.53-73.93mm
  • Canon patents
    • 4-group zoom of positive and negative positive negative
    • Inner folder – Kas (Group 3)
    • The fourth lens unit can also be used for anti-vibration

Canon Patent For 70-400 f/4.5-5.6 Lens

2014_21256_fig05

Egami (translated) spotted another patent filed by Canon. It appears that Canon is working on a 70-400mm f/4.5-5.6 lens.

  • Patent Publication No. 2014-21256,2014-21257
    • Publication date 2014.2.3
    • Filing date 2012.7.18
  • Example 2
    • Zoom ratio 5.45
    • Focal length f = 71.33-144.71-388.95mm
    • Fno. 4.63-4.84-5.83
    • Half angle ω = 16.87-8.50-3.18 °
    • Image height Y = 21.64
    • 240.00-284.68-303.83mm overall length of the lens
    • BF 75.92-79.30-95.93mm
    • 6-group zoom of positive and negative positive and negative positive and negative
    • (Part of the fourth group) anti-vibration
    • Rear Focus (Group 6)

Canon Patent For Ring Flash With Prism For Uniform Light Distribution

Canon Patent

Egami (translated) spotted another patent filed by Canon, this time for a ring flash with a prism for an uniform distribution of the light.

  • Patent Publication No. 2014-13350
    • Publication date 2014.1.23
    • Filing date 2012.7.5
  • Existing ring strobe
    • Xenon tube
    • Process to bend the arc shaped glass tube cylindrical difficult
  • Canon patents
    • There are two areas in light of the strobe
    • Light flux from the first region is subject to direct
    • Toward the object light beam from the second zone enters the prism, and then reflected inside
    • Provided with a step stepped on the reflecting surface, by changing the pitch of the step, it is possible to adjust the distance between the emission point

More after the break.

Click here to open the rest of the article

Canon Patent for Curved Diaphragm

Curved Diaphragm Curved Diaphragm

Egami (translated) spotted another patent filed by Canon (we had more Canon patents lately: 1 | 2 | 3).

The patent refers to the implementation of a curved diaphragm. I guess this could be very useful for miniaturization purposes. Is there another super-small DSLR like the Rebel Sl1 (price & specs) coming?

  • Patent Publication No. 2014-13363,2014-13365
    • Publication date 2014.1.23
    • Filing date 2012.6.6
  • Canon patents
    • The iris of the dome-shaped
