And yet another Canon patent application. Fast primes for the RF mount.

Canon patent application 2022024113 (japan, published 8/30/2023) discusses optical formulas for three fast prime lenses:

• 24mm F1.4
• 35mm F1.4
• 50mm F1.4

From the patent literature:

Optical system and imaging device

A compact optical system capable of high-speed focusing with a wide angle of view and a large aperture ratio is provided.

Description of the Related Art

Imaging devices using solid-state imaging devices such as CCD sensors and CMOS sensors are required to have optical systems that have a wide angle of view, a large aperture ratio, a small size, and high optical performance. There is also a demand for high-speed autofocus in the optical system.

An optical system with a wide angle of view and a large aperture ratio has the problem that it is difficult to correct various aberrations. In particular, if the weight of the focus lens group is reduced in order to perform high-speed focusing (autofocus), it becomes difficult to suppress aberration fluctuations in focusing from an object at infinity to a close object.

According to the present invention, it is possible to provide a compact optical system capable of high-speed focusing while having a wide angle of view and a large aperture ratio.

Example 1 (24mm F1.4)

• Focal length 24.36
• F value 1.44
• Half angle of view 41.61
• Image height 21.64
• Lens length 106.56
• Back focus 12.72

Example 2 (35mm F1.4)

• Focal length 34.09
• F value 1.45
• Half angle of view 32.40
• Image height 21.64
• Lens length 113.84
• Back focus 13.67

Example 3 (50mm F1.4)

• Focal length 48.50
• F value 1.45
• Half angle of view 24.04
• Image height 21.64
• Lens length 108.70
• Back focus 11.47

More Canon patents are listed here.

[via Digicame Info]

A new Canon patent was spotted. Will this lens ever hit the shelves? Unlikely in our opinion.

Canon patent application 2023077336 (Japan, published 6/5/23) discusses optical formulas for a 35mm f/1.3 lens.

An object of the present invention is to realize an optical system capable of reducing ghosts in a desired wavelength region in spite of having a large aperture and a small lens.

BACKGROUND OF THE INVENTION

1. Field of the Invention
The present invention relates to an optical system and the like, and is suitable for imaging apparatuses such as digital video cameras, digital still cameras, broadcast cameras, surveillance cameras, cameras for wearable devices, and cameras for mobile devices.

2. Description of the Related Art
There is a demand for a high-performance optical system that reduces the occurrence of ghosts and flares. In order to reduce the occurrence of ghosts and flares, a method of providing an antireflection film on the lens surface is known.
In recent years, optical systems have become larger in diameter and smaller in size, and the opening angle of lenses tends to increase. However, due to problems in manufacturing the antireflection film, the antireflection effect in the periphery of the lens with a large opening angle may be inferior to the antireflection effect in the position on the optical axis.

SUMMARY OF THE INVENTION

Accordingly, it is an object of the present invention to provide an optical system capable of reducing ghosts, particularly in a desired wavelength region, while having a large aperture and a small lens.

Example 1

• Focal length: 12.40
• F-value: 1.30
• Half angle of view: 32.82
• Image height: 8.00
• Overall length: 21.76
• Back focus: 0.44

Example 2

• Focal Length: 33.53
• F-value: 1.30
• Half angle of view: 32.83
• Image height: 21.64
• Overall length: 61.97
• Back focus: 0.29
