Canon Patent For RF 90mm f/2.8L IS Macro Lens (EOS R System)

Canon Patent

Hi Lows Note spotted a rather interesting Canon patent application (2017-108266).

The patent literature describes a 90mm f/2.8L IS macro lens for the Canon EOS R system. Two optical formulas are discussed in the patent literature.

Specification and lens arrangement of embodiment 1

  • Focal length: 97.00mm
  • F number: 2.92
  • Half angle of view: 12.57
  • Image height: 21.64mm
  • Lens length: 115.12mm
  • Back focus: 20.01mm

Specification and lens arrangement of embodiment 3

  • Focal length: 86.00mm
  • F number: 2.87
  • Half angle of view: 14.12
  • Image height: 21.64mm
  • Lens length: 115.07mm
  • Back focus: 15.93mm

Well, this is a patent application for a lens that may indeed hit the market (most patent applications never become a real product).

More Canon patent applications are listed here. Some particularly interesting patent applications we think might get into production in the next few years are these:

IRIX 150mm f/2.8 Macro 1:1 Lens Pre-Order Available At $595

IRIX 150mm F/2.8

At a glance:

  • EF-Mount Lens/Full-Frame Format
  • Aperture Range: f/2.8 to f/32
  • Neutrino Coating
  • 1:1 Magnification, 1.1′ Minimum Focus
  • Manual Focus Design with Focus Lock
  • Depth of Field and Focus Distance Scales
  • Dragonfly Weather-Sealed Construction
  • Rounded 11-Blade Diaphragm

The IRIX 150mm f/2.8 Macro 1:1 lens can now be pre-ordered for $595 at B&H Photo | Adorama | Focus Camera. The video below tells you about the lens.

Deal: Canon EF 100mm f/2.8L Macro IS – $699 (reg. $899)

Canon RF 100mm F/2.8L

Canon EF 100mm f/2.8L Macro IS at a glance:

  • EF-Mount Lens/Full-Frame Format
  • Aperture Range: f/2.8 to f/32
  • One Ultra-Low Dispersion Element
  • Super Spectra Coating
  • 1:1 Magnification, 11.8″ Min. Focus
  • Ring-Type Ultrasonic Motor AF System
  • Focus Range Limiter
  • Optical Image Stabilizer
  • Weather-Sealed Construction
  • Rounded 9-Blade Diaphragm

B&H Photo has the Canon EF 100mm f/2.8L Macro IS lens on sale at $699. Compare at $899. This is a very good deal, grab it before it’s over.


More selected and exclusive deals…

Irix 150mm f/2.8 MACRO 1:1 Lens Announced

Irix 150mm F/2.8

A new and pretty interesting lens has been release ahead of Photokina 2018, the Irix 150mm f/2.8 MACRO 1:1. It will obviously come in a Canon EF mount version.

Press release:

IRIX, a European brand already known for its high-quality wide-angle lenses (Irix 11mm f/4.0, Irix 15mm f/2.4) and photographic filter systems is expanding its portfolio with a new lens – the Irix 150mm f/2.8 Macro 1:1, designed for full frame cameras with the Nikon F, Canon EF, and Pentax K mount.

With its focal length of 150mm and 1:1 scale of reproduction, these are the basic features of the new product that allows comfort working with small objects. Thanks to the possibility of being able to move away from the photographed object, this makes the operation more convenient than using lenses with a shorter focal length. No shadows are cast on the object and it is also possible to use lamps dedicated to this type of photography.

The Irix 150mm f/2.8 Macro 1:1 lens is equipped with an aperture mechanism consisting of 11 rounded blades that maintain a circular shape within the entire available working range. Thanks to this, when shooting with a wide open aperture, a pleasant background blur is obtained; when closed right down, the diffraction appears much later. This ensures much greater detail of the image.

The focus ring has been equipped with a wide rubber handle with a special convexity pressing. To facilitate precise focusing of the scale, with 270 degree rotation. The whole design is complemented by a functional Focus Lock ring that allows you to lock the focus ring at a convenient position.

The Irix 150mm f / 2.8 Macro 1:1 lens has been sealed in key points (the front element, the Focus Lock ring, the focusing ring and bayonet), making it suitable for use in theharshest of weather conditions such as fog, rain or snow.

The optical design consists of twelve elements – three of which are made of super-low dispersion glass (ED), another four of glass with a higher refractive index (HR), and the whole arranged into nine optical groups. Thanks to this construction, we obtain an close to zero distortion (at a level of 0.1%).

The Irix 150mm f/2.8 Macro 1:1 lens is equipped with an internal focusing system (IF) so that the lens does not change its dimensions when focusing, thus maintaining a compact size and better sealing.

The Irix 150mm f / 2.8 Macro 1:1 lens is the first model available in the new version with the Dragonfly finish, in which the aluminium frame has been enclosed in an external structure made of aluminium-magnesium alloys and composite elements. The combination of Firefly and Blackstone features gave the lens lightness and solidity while maintaining high mechanical strength and resistance in difficult weather conditions.

The lens has a CPU that allows control of the lens aperture from camera level, and the AE module allows the use of semi-automatic modes (PASM). This solution allows the user to get confirmation of the focus from the camera. An additional benefit is the recording of exposure data in the EXIT format.

A set with the lens will include:

  • a practical deep lens hood that isolates the lens from sidelight sources and also protects the front element of the lens from minor damage
  • a rigid lens case for safe transport and storage
  • a detachable tripod collar (Arca Swiss standard), allowing you to transfer the weight that is the centre of gravity to the front and securely place the camera on a tripod.

Information on availability and prices will be provided at a later date. At the same time, we would like to invite all interested parties to visit the Irix stand during the Photokina 2018 fair in Cologne.

You can find us at hall 4.2, stand D030 where the lens will be made available to a wide audience.

Deal of the Day: Bolt VM-160 LED Macro Ring Light – $49.95 (reg. $109.95)

Macro Ring Light

Bolt VM-160 LED Macro Ring Light at a glance:

  • Guide Number: 21′ / 6.4m at ISO 100
  • Eighteen High-Output LEDs
  • Six Levels of Brightness Adjustment
  • Continuous Light & Flash Modes
  • Left & Right Only Illumination Modes
  • 1.6″ Backlit LCD Display
  • Clear, Frosted, Blue, & Amber Diffusers
  • Eight Adapter Rings from 49-77mm
  • Stand/Tripod Mount Included
  • Runs on 4 AA Batteries

Only for today (9/20/18) B&H Photo has the Bolt VM-160 LED Macro Ring Light on sale at $49.95. Compare at $109.95. Free shipping.


More selected and exclusive deals…



Sigma 70mm f/2.8 Macro ART Review (D. Abbott)

Sigma 70mm F/2.8 DG Macro Art

Sigma 70mm f/2.8 Macro ART at a glance:

  • EF-Mount Lens/Full-Frame Format
  • Aperture Range: f/2.8 to f/22
  • Two FLD Elements, Two SLD Elements
  • Low Dispersion and Aspherical Elements
  • Super Multi-Layer Coating
  • 1:1 Magnification, 10.2″ Min. Focus
  • Coreless DC AF Motor, Manual Override
  • Weather-Sealed, Brass Bayonet Mount
  • Rounded 9-Blade Diaphragm
  • Compatible with Sigma USB Dock

Dustin Abbott completed his comprehensive review of the Sigma 70mm f/2.8 Macro ART lens.

From the conclusion;

[…] the Sigma 70mm f/2.8 Macro | ART is a somewhat quirky lens.  It deviates from the path established for the ART series on a number of levels, and also deviates from the modern standard of what a macro lens should have (Image Stabilization, Internal Focus, etc…)  The one area where it is very much a Sigma ART lens is in the optical performance, where it delivers as good a performance as I’ve seen from a macro lens outside of bokeh that is a little busy in some situations.  I’m less impressed by the decision about the focus motor, at least on DSLRs […]

Dustin Abbott’s review comes with a huge set of sample pictures and analyses all aspects of the Sigma 70mm f/2.8 Macro ART. For those who prefer to watch, the video review below tells everything.

Sigma 70mm f/2.8 Macro ART: B&H Photo | Adorama | Amazon
