Canon Patent: 100-400mm f/5.5-7.1 Lens For APS-C Camera

canon patent
View Post

Here is an inetersting Canon patent for a 100-40mm lens.

Canon Patent Application 2020-027156 (Japan) discusses optical formulas for a 100-400mm f/5.5-7.1 lens. The interesting fact is that this 100-400mm f/5.5-7.1 is for APS-C cameras. For the EOS-M system? We think rather not but it is possible. For sure it seems to be consumer lens.

  • Focal length:        119.97 218.00 360.96
  • F-Number:             5.50   6.50   7.10
  • Half angle of view:  6.50   3.59   2.17
  • Image height:         13.66  13.66  13.66
  • Total lens length:   179.62 192.93 233.56
  • BF:                   15.03  15.03  15.04

More Canon patent applications are listed here. Some particularly interesting patent applications we think might get into production are these:

Canon Patent: RF 17-70mm Lens For EOS R Camera System

canon patent
View Post

Might this Canon patent application lead to a product that will actually hit the shelves? We’ve not made up our mind so far.

Canon patent application 2020-012922 (Japan) discusses optical formulas of what might become a future kit lens for the Canon EOS R full frame mirrorless system. The patent literature discusses formulas for two 17-70mm and a 16-60mm lens, and for both the EF and the RF mount. We think the RF mount lens is the one to have an eye on. The discussed lenses:

Canon EF mount:

  • Focal length 17.40 35.00 68.00
  • F-number 3.33 4.09 5.88
  • Half-field angle (degree) 51.19 31.72 17.65
  • Image height 21.64 21.64 21.64
  • Total lens length 168.42 153.33 168.42
  • BF 38.32 53.44 84.11
  • Focal length 16.30 35.00 60.00
  • F-number 3.31 4.22 5.88
  • Half angle of view (degrees) 53.01 31.72 19.83
  • Image height 21.64 21.64 21.64
  • Total lens length 68.46 153.33 168.42
  • BF 38.35 56.15 83.82

Canon RF mount:

  • Focal length 17.40 34.99 67.97
  • F-number 3.31 4.12 5.88
  • Half angle of view (degrees) 51.20 31.73 17.66
  • Image height 21.64 21.64 21.64
  • Total lens length 168.41 154.99 168.39
  • BF 8.36 52.48 81.91

More Canon patent applications are listed here. Some particularly interesting patent applications we think might get into production are these:

Canon Patent: IBIS Might Come To The Canon EOS M and PowerShot Lineup Too

canon patent
View Post

We have no doubts that Canon will feature IBIS (In Body Image Stabilisation) on future cameras, given the remarkable collection of patent applications dealing with it and the fact that a Canon exec told the world about. And it’s very likely that the first Canon camera to feature it will be mirrorless.

Never the less, Canon patent application 2019-219650 (Japan) discusses how to feature IBIS on what seem to clearly be cameras in the Canon EOS M and Canon PowerShot lineup. So, IBIS coming to the m ore entry level oriented Canon cameras? Maybe not soon, but maybe sometime.

canon patent

More Canon patent applications are listed here. Some particularly interesting patent applications we think might get into production are these:

Canon Patent: Canon RF 135mm f/1.4L USM Lens (EOS R System)

canon patent
View Post

And yet another Canon patent application for yet another RF lens.

Canon patent application discusses the optical formula for an RF 135mm f/1.4L USM for the Canon EOS R full frame mirrorless system.

  • Focal length: 131.00mm
  • F-Number: 1.41
  • Half angle of view: 9.38°
  • Image height: 21.64mm
  • Total lens length:  182.28mm
  • BF: 13.87mm

We think this Canon patent application has a good chance to hit the market. In other words: we might see such a lens sooner or later.

More Canon patent applications are listed here. Some particularly interesting patent applications we think might get into production are these:

Canon Patent: RF 24-100mm f/2.8 & RF 24-85mm f/2.8 Lenses For The EOS R System

canon patent
View Post

Here is very interesting Canon patent application (2020-8773A, Japan) for two zoom lenses for the EOS R full frame mirrorless camera system. Might be a patent application that hits the market sooner or later.

The lenses described in the patent application appear to be for the RF lens mount, i.e. for the Canon EOS. Optical formulas for an RF 24-100mm f/2.8 and an RF 24-85mm f/2.8 lens are discussed in the patent application.

Embodiment 1: 24-85mm f/2.8

  • Focal length: 24.70 50.00 85.00 mm
  • F number; 2.90 2.90 2.90
  • Half angle of view: 41.22 23.40 14.28
  • Image height: 21.64 21.64 21.64 mm
  • Lens length; 153.30 173.51 198.31 mm
  • Back focus: 12.00 26.12 43.44 mm

Embodiment 2: 24-100mm f/2.8

  • Focal length: 24.70 50.00 101.85 mm
  • F number: 2.91 2.91 2.91
  • Half angle of view: 41.22 23.40 11.99
  • Image height: 21.64 21.64 21.64 mm
  • Lens length: 158.52 176.33 218.42 mm
  • Back focus: 10.00 26.38 43.15 mm

More Canon patent applications are listed here. Some particularly interesting patent applications we think might get into production are these:

[via Hi Lows Note]

US Patents: Canon World’s Only Company To Be Ranked Among Top 5 For 34 Years

canon patent application
View Post

Well, still there is some people loudly claiming Canon doesn’t innovate. We feature a lot of Canon patent applications, and they are all listed here.

this Canon patent application

Canon’s press release:

It’s Official: Canon Places 3rd in IFI CLAIMS 2019 U.S. Patent Rankings

The Only Company in the World to be Ranked in Top Five for 34 Years

MELVILLE, NY, January 15, 2020 – Aligning with its mission of empowering innovations, Canon U.S.A., Inc., a leader in digital imaging solutions, is proud to announce that its parent company, Canon Inc., was granted 3,548 patents by the US Patent and Trademark Office and maintained its third place ranking for patents granted in 2019 according to IFI CLAIMS Patent Services, a leading producer of global patent databases. With this year’s ranking, Canon has become the only company in the world to have ranked in the top five for number of patents granted for 34 consecutive years. Additionally, Canon has once again ranked first in patents among Japanese companies for the 15th consecutive year.

These patents continue to demonstrate Canon’s contribution to science and technology which are used to develop fundamental technologies designed to drive innovation and support customer and business needs.

“As technology continues to evolve, we too will continue exploring new areas and future innovation opportunities,” said Seymour Liebman, executive vice president, chief administrative officer and general counsel, Canon U.S.A. Inc. “Canon is proud to be in the top three patent holders as it reflects our dedication and commitment to delivering innovative ideas and solutions to meet market and customer demands.”

For more information on Canon and its products, please visit www.usa.canon.com.
