A new Canon patent application for an RF mount lens. The interesting fact here: it seems to be be made for a camera with APS-C sensor. Is the EOS R with crop sensor really coming?
Canon patent application 2021-162822 (Japan, spotted by asobinet.com) discusses optical formulas for a 18-45mm f/4.5-6.3 lens. A kit lens you might add. From the patent literature:
PROBLEM TO BE SOLVED: To provide a lightweight zoom lens.
As a zoom lens used in an imaging device such as a still camera, a video camera, and a surveillance camera, Patent Document 1 discloses a negative lead type zoom lens in which the lens group on the most object side has a negative refractive power.
- Focal length: 18.53-43.65
- F value: 4.54-6.50
- Half angle of view: 33.78-17.38
- Image height: 12.40-13.66
- Overall length: 92.00-83.05
- Back focus: 30.20-51.20
- Focal length: 20.01-43.64
- F value: 4.60-6.50
- Half angle of view: 31.79-17.38
- Image height: 12.40-13.66
- Overall length: 90.65-80.61
- Back focus: 32.94-50.55
This definitely appears to be a lens for a APS-C sensors. asobinet.com notes that:
[…] the image height on the wide-angle side is 12.40 mm, which is a little too small, so it may be stretched by image processing. Since the back focus is longer overall, is it a mirrorless lens that uses a retractable structure? It’s similar to the patent application that appeared in 2019, but this time it’s different. The focal length at the wide-angle end is as low as 18.53mm, and you may feel that the angle of view is a little narrow for movie shooting.
The lens might also be for the EOS M system, although it seems less likely. Is an EOS R with an APS-C sensor really on Canon’s radar? We still have a somewhat hard time to believe it but there are signs it might be true. All comments welcome.
